3. Being sure the striker is in fired position, unscrew the receiver end cap and remove it toward the rear.

4. Move the bolt toward the rear until the bolt handle aligns with the larger opening at the rear of its slot in the receiver, and remove the bolt handle toward the right.

5. Remove the bolt assembly from the rear of the receiver.

6. Drifting out the cross pin in the bolt, just to the rear of the bolt handle hole, will release the striker and its spring, and the bolt spring and its guide, toward the rear. Caution: Both of these springs are under tension, and this entire assembly will be instantly released when the drift pushing out the cross pin is withdrawn. Retard the springs and let the tension off slowly.
