Gun Digest Hi-Power Assembly/Disassembly Instructions by J.B. Wood

Author:J.B. Wood
Language: eng
Format: epub
ISBN: 978-1-4402-3172-8
Publisher: F+W Media
Published: 2011-10-10T04:00:00+00:00

12. With the hammer down, drift out the sear pin and remove the sear from the top of the frame.

13. Draw the hammer back to compress the mainspring upward, and lift the sear spring stud (arrow) from its recess at the bottom of the grip frame. Remove the sear spring forward, into the magazine well.

14. Rotate the ejector (arrow) forward and down to free the safety catch.

15. The safety can now be removed from the left side of the frame. Driving out the small vertical pin in the safety will release the detent plunger and spring.
