Gun Digest Buck Mark Assembly/Disassembly Instructions by J.B. Wood

Author:J.B. Wood
Language: eng
Format: epub
ISBN: 978-1-4402-3171-1
Publisher: F+W Media
Published: 2011-10-10T04:00:00+00:00

14. Remove the left grip, and lift off the slide-latch.

15. With the hammer in cocked position, insert a small tool such as a screwdriver or a pointed drift in the access hole near the upper curve of the frame backstrip, to catch and restrain the hammer spring plunger.

16. Gently pry the safety click plate outward, off the ends of the two pins. Remove the plate outward.

17. Push the sear forward, and turn the hammer up to its fired position. Push the hammer pivot pin out toward the left. If necessary, the slide latch spring can be detached from its groove in the end of the hammer pivot pin.
