Gun Digest American Arms ATI GSG-5 Assembly/Disassembly Instructions by Kevin Muramatsu

Author:Kevin Muramatsu [Muramatsu, Kevin]
Language: eng
Format: epub
ISBN: 978-1-4402-3162-9
Publisher: F+W Media
Published: 2011-07-24T21:00:00+00:00

27. Remove these two screws to access the grip screw. Caution: the internal slots that these screws turn into are very easily stripped.

28. Remove the grip screw and the trigger housing can be pulled from the pistol grip.

29. There are two brass spacers sitting on top of a large plate, which is the firing pin safety arm. There is a spring pushing this plate to the rear. Remove the spacers and then gently remove this plate and the spring from the slot underneath it. The J shaped trigger bar below it is riveted to the trigger housing and should not be removed.
