To resume, the loops for(i=[ ]) permits to obtain the above figure and the loop with the variable j permits to rotate the whole of 60 degrees twice to obtain the figure below.

The program

The ring that surrounds the flower() module is obtained by doing the difference() { } of two cylinders (lines 61 to 64 of the code). It is colored in red on the figure below.

Then, the union() { } command permits the association between the ring and the flower() module. But in order to insert the flower correctly in the ring, we undertake a little rotation of 15 degrees of the flower() module, as well as a resizing at the diameter desired with the rezise([0.9*diam,0.9*diam,ep]) command.

Here you go ! Your flower of life is ready to be compiled, saved and printed ! To compile it, you can use the keyboard shortcut F6 or click on the corresponding button. Don't be surprise if this step takes a few minutes : the file is complex ! Then, you can save it as STL format on your computer.
