Materials

• 1¼ x 1¼" x 12 gauge steel (35 feet)

• 8 feet of 1" x 1 x 12-gauge steel tubing

• 3/16" x 2" flat bar (2 feet)

• ¼" round stock (1 foot)

• Hex bolts and nuts 5/16- 18 UNC (4)

• ¾ to 1" thick Plywood (16 x 24")

Building the Top Frame

1. Cut the top long pieces (B) to 24".

2. Cut the top short pieces (C) to 13½".

3. Align the top long pieces (B) and top short pieces (C) at 90°. Use a corner magnet to hold the pieces together squarely.

4. Check for square again. Use a magnetic clamp or simply hold the parts in place as you tack them together. Tack all of the long and short tops together to create the top frame.

5. Check for square again, and then weld the four pieces together.

Note: Recommended methods for all welds: SMAW 3/32" E 6013 electrode; GMAW short circuit transfer; GTAW; ER 70S-6 filler metal, or MIG (as shown here).
