Three Phase Electrical Circuit Analysis by Craig Scheckle

Author:Craig Scheckle
Language: eng
Format: epub
Publisher: Bookboon.com Ltd.
Published: 2017-12-06T00:00:00+00:00

Figure 2.15

Figure 2.16

Example 3:

Illustrating the application of Kirchoff’s laws is best shown by analysing a parallel connected circuit. This principle will be used in later chapters when Delta connected three phase circuits are examined.

Figure 2.17 shows a single phase supply connected to a parallel connected network. To determine the power delivered by the source we need to know the applied voltage, the current and the phase angle between the voltage and the current. The power delivered is then;
