Making Things Move DIY Mechanisms for Inventors, Hobbyists, and Artists by Dustyn Roberts

Author:Dustyn Roberts [Roberts, Dustyn]
Language: eng
Format: epub, pdf
Tags: Carpentry, Technology & Engineering, Construction, Inventions, Mechanical
ISBN: 9780071741682
Google: L71QLEHYE0sC
Publisher: McGraw Hill Professional
Published: 2010-12-06T21:23:48+00:00

4. Connect pin 1 to ground.

5. Connect pin 2 and pin 6 of the 555 timer with a short jumper.

6. Also connect pin 2 to one of the outside legs of a potentiometer.

7. Also connect pin 2 through a 0.1 µF capacitor to ground.

8. Connect pins 4 and 8 with a small jumper wire. Connect pin 8 to the 5V battery power column and to the other outside leg of the potentiometer. Refer to Figure 6-27 for a close-up of the completed breadboard circuit.

9. Connect pin 5 to ground through a 0.1 µF capacitor.

10. Connect pin 7 to the middle leg of the potentiometer.

11. Plug the transistor into the breadboard as shown so each of the three legs has its own row (see Figure 6-27).

12. Connect the output pin 3 on the 555 chip to the base of the transistor.

FIGURE 6-27 Using a 555 timer to PWM a motor, detailed view
