Elementary forge practice; a text-book for technical and vocational schools by Harcourt Robert H. (Robert Henry)

Author:Harcourt, Robert H. (Robert Henry)
Language: eng
Format: epub, pdf
Tags: Forging
Publisher: [Peoria, Ill.] : Manual arts press
Published: 1920-03-25T05:00:00+00:00

Fig. 42. SPLIT WELD FOR HEAVY STOCK.

being pointed and the other split and shaped like a Y. The pieces are then driven together and closed down, one on the other, ready for welding, as shown at B, Fig. 42.

C D

Fig. 43. WELDING TIP ON A PICK.

This weld, or one very similar to it, is often used when welding tool steel to iron or to machinery steel. An example of this is the "steeling" of the Norway iron body of a pick, shown at A, Fig. 43. The ends of this body are split and shaped as shown at B. The piece to be welded on is about Y-Z x 1 inch and from 4 to 5 inches long. It is pointed and
