Electronic Measuring Instruments: Learn Electronics by Wilson Jessica
Author:Wilson, Jessica [Wilson, Jessica]
Language: eng
Format: epub
Published: 2020-07-07T16:00:00+00:00
Delay Line − It provides some amount of delay to the signal, which is obtained at the output of vertical amplifier. This delayed signal is then applied to vertical deflection plates of CRT.
Trigger Circuit − It produces a triggering signal in order to synchronize both horizontal and vertical deflections of electron beam.
Time base Generator − It produces a sawtooth signal, which is useful for horizontal deflection of electron beam.
Horizontal Amplifier − It amplifies the sawtooth signal and then connects it to the horizontal deflection plates of CRT.
