Colour Light Signalling for Model Railways by Paley Simon;

Author:Paley, Simon;
Language: eng
Format: epub
Publisher: Crowood

Fig. 133 The Southern way of mounting signals on a classic Southern precast concrete cantilever structure (at the front) and on a fabricated steel version (behind) at Clapham Junction. MIKE ROMANS

Fig. 134 The depot exit signal at the east end of Reading maintenance depot. Photo taken in a position of safety and under the supervision of a Network Rail COSS.

DEPOTS AND FREIGHT YARDS

Rolling-stock maintenance depots and freight marshalling yards can employ signalling in a number of different ways. The most common is that the vast majority of moves taking place within a yard are not controlled by the main-line signaller. This is to reduce the workload of the signaller by not bothering them with regular shunting moves, something touched on in Chapter 5. The only signalling in depots/yards tends to be an exit signal and perhaps signalling in and out of a headshunt (depending upon its location relative to the arrival/departure lines). In this case, you may have ‘opposing locking omitted’ to enable both signals to be pulled off at the same time.
