FORMING THE END FRAMES

I Cut the top pieces (A), uprights (B), and bases (C) to the sizes listed in the Bill of Materials for the two end frames. Then, using the drawing below for reference, mark the radii for all of the curves on the tops and bases.

TOP AND BASE PARTS VIEW

R = 1" h 6Va"

V^

2"

•Mi*

J~

i

R = '/ 2 "

©

1 W

I me

-814*--12%"-

Ar

2 Cut a piece of scrap that's at least as long as the base pieces (12'/2"). Now, clamp the scrap to the bottom edge of one of the base pieces as shown in the photo below. Clamp these two pieces to your drill press table, and bore the two 1" holes and four 2" holes where marked to form the radii. Repeat these operations on the other base. (If you don't have the 1" and 2" drill bits, you can cut the radii to shape on a band saw)
