Windows 10 for the Internet of Things by Charles Bell

Author:Charles Bell
Language: eng
Format: epub
Publisher: Apress, Berkeley, CA

DPST: Double pole, single throw

SPDT: Single pole, double throw

DPDT: Double pole, double throw

3PDT: Three pole, double throw

There may be other variants that you could encounter. I like to keep it simple: if I have just an on/off situation, I want a single throw switch. How many poles depends on how many wires or circuits I want to turn on or off at the same time. I use these for double throw switches when I have an “A” condition and a “B” condition in which I want A on when B is off, and vice-versa. I sometimes use multiple throw switches when I want A, B, and off situations. I use the center position (throw) as off. You can be very creative with switches!
