We can use the tools introduced in section (2) above to understand in a semi-quantitative way what antenna configurations make sense. For example, in the portal configuration of Figure 6.21, how many antennas are needed, and where should they be placed? We can make a first estimate by applying the procedure of Figure 6.5 to roughly sketch out the read zone, using a 6 dB beam width of about 120° obtained from the typical patch antenna pattern of Figure 6.16. In Figure 6.22 we show such an estimate overlaid on a 3-meter-square doorway, assuming the maximum read range in beam center is a conservative 3 meters. It’s apparent that a single pair of antennas, either both on one side or both at one elevation, will not cover the whole area of the doorway, but a pair of antennas on each side does a good job.
