The Essentials of Power System Dynamics and Control by Hemanshu Roy Pota

Author:Hemanshu Roy Pota
Language: eng
Format: epub, pdf
Publisher: Springer Singapore, Singapore

6.Run a dynamic simulation starting from the steady-state solution obtained above for 1 sor so. After each integration step Eq. (2.106) should be used to obtain and these current values are input for the next integration step.

(a)Perform an integration step as shown in the block diagram in Fig. 2.2 for each device, and obtain , .

(b)Obtain from (2.106). Go to Step 6a and continue till the end of the simulation period.

7.Apply a disturbance, e.g., increasing the input synchronous machine power by fifty per cent, and perform dynamic simulation.
