The Arduino Project Handbook by Mark Geddes
Author:Mark Geddes
Language: eng
Format: epub
Publisher: No Starch Press
Published: 2016-08-17T04:00:00+00:00
The potentiometer controls the contrast of the LCD screen.
THE BUILD
Prepare the LCD screen as per the soldering instructions in “Preparing the LCD Screen” on page 104.
Place your LCD screen in the breadboard, inserting the header pins into the breadboard holes. Also place the potentiometer in the breadboard, and use the breadboard and jumper wires to connect your LCD screen, Arduino, and potentiometer.
LCD SCREEN
ARDUINO
1 VSS
GND
2 VDD
+5V
3 VO contrast
Potentiometer center pin
Download
