The Analysis and Design of Linear Circuits, Tenth Edition by unknow

Author:unknow
Language: eng
Format: epub
ISBN: 9781119913443
Published: 2023-03-01T00:00:00+00:00

EXAMPLE 10–11

The circuit in Figure 10–27 (a) is in the zero state. convert the Norton subcircuit to the left of points A and B into its Thévenin equivalent. Then apply voltage division to find the s -domain relationship between the input I 1 ( s ) and the output V 2 ( s ).

FIGURE 10–27

SOLUTION:

In this example, we use a source transformation on the subcircuit to the left of points A and B in Figure 10–27 (a). This Norton subcircuit consists of an independent current source I N = I 1 ( s ) in parallel with an impedance Z N = R . The equivalent Thévenin circuit consists of a voltage source V T = I N Z N = RI 1 ( s ) in series with an impedance Z T = Z N = R . Figure 10–27 (b) shows the circuit after the source transformation. Applying voltage division in the modified circuit yields the required input-output relationship.
