Revit 2020 for Architecture by Eric Wing

Author:Eric Wing [Wing, Eric]
Language: eng
Format: epub
ISBN: 9781119560142
Publisher: Wiley
Published: 2019-11-26T00:00:00+00:00

FIGURE 8.9 Draw the new grid by picking two points.

OK, great! Now, let's start adding our horizontal grids. We are going to do this in an incredibly similar fashion to how we did the vertical grids.

Zoom in to the west side of the east building, as shown in Figure 8.10.

Right‐click on grid 1 and select Create Similar.

On the Draw panel, select the Pick Lines button, as shown in Figure 8.10.

Pick the center of the north horizontal wall.

As we have done before, select the grip at the end of the grid line, and drag the line to the left.

Click the Show Bubble button to turn on the bubble.

Rename the grip to A, as shown in Figure 8.11.

Go to the other side of the building and drag the grid to the right to resemble Figure 8.12. Be sure it is stretched out far enough to clear the radial wall because we will be copying this grid down multiple times.

OK! Now copy grid A to the center of the walls shown down to grid F. You can do it! See Figure 8.13.
