Figure 7-22 Model after creating the hole on the cylindrical feature

Saving the Model

You need to save the model because you may need it later.

1. Choose the Save button from the File menu and then save the model. The order of feature creation can be seen from the Model Tree shown in Figure 7-23.

Figure 7-23 The Model Tree for Tutorial 4

Creating a Simplified Representation View of the Model

1. Choose Manage Views > View Manager from the Model Display group of the View tab; the View Manager dialog box is displayed.
