By thermal magnetic circuit breakers (MCCBs) normally with fixed time delay characteristic and in large sizes with adjustable instantaneous magnetic characteristics, see Chapter 6

With MCPs which have only instantaneous magnetic characteristics adjustable over a certain range; the MCPs do not have a short-circuit rating of their own and are tested with motor contactor starters

FIGURE 10.13

Stabilization of a motor contactor for voltage dip.

10.7 Two-Wire and Three-Wire Controls

In a three-wire control, the contactor is maintained through an auxiliary contact in parallel with the start push button. This is the most common control used in the industry. If the contactor opens due to a low voltage, the coil circuit is broken by the auxiliary contact of the contactor; and the motor cannot restart unless the start push button is again operated. This control is referred to as three-wire control with loss of voltage protection, see Figure 10.14a.

A synchronous motor on loss of voltage acts as a generator for a short period of time and tends to maintain the AC terminal voltage for a longer period than an induction motor. See undervoltage protection for further explanation.

Figure 10.14b shows a as two-wire control. Here, the auxiliary contact of the contactor is omitted. The start–stop push button is replaced with a toggle or latched switch, pressure switch, or other types of maintained contact sensing device. The contactor will drop out at a certain low voltage and the motor will automatically restart when the voltage is restored. This is referred to as two-wire control and loss of voltage release. This has the disadvantage that many motors provided on the same bus will restart simultaneously, which will depress the voltage to an extent that the motors will never be able to restart. When two-wire controls are used, overload relays with automatic reset should not be applied. This will make the motors restart when the relays are self-reset.
