Physics of Semiconductor Devices by Massimo Rudan

Author:Massimo Rudan
Language: eng
Format: epub, pdf
Publisher: Springer International Publishing, Cham

(18.63)

whence

(18.64)

Fig. 18.14Density of states in an n-doped semiconductor, where the high concentration of the dopant produces the band-gap narrowing. The gap’s extension is arbitrary and does not refer to any specific material

To calculate the carrier concentrations when band-gap narrowing is present, one must replace E C with in the second relation of (18.56), and E V with in the second relation of (18.57), to find

(18.65)

(18.66)

Band-gap narrowing makes ξ e , ξ h to increase with respect to the moderately doped case; as a consequence, the equilibrium carrier concentrations n and p are larger as well. As mentioned in Sect. 18.3, band gap is measured by either electrical or optical methods. The results of gap’s measurements, that show that E G decreases when the dopant concentration exceeds some limiting value N r , are usually rendered in compact form by means of interpolating expressions, an example of which is, for silicon [125], [126],
