Make Your Own PCBs with EAGLE by Simon Monk

Author:Simon Monk
Language: eng
Format: epub
Publisher: McGraw-Hill Education
Published: 2017-03-16T04:00:00+00:00

SMD Hand Soldering

As long as the SMDs you use are at the larger end of the size scale and have pins on the edges of the device rather than on the underside, then they can be soldered relatively easily using a regular soldering iron. The main problem is that they are so light, and because they do not have leads projecting through the holes, there is nothing to hold them in place when you try to solder them.

Soldering Two- and Three-Legged Components

The sequence of steps to solder a 1206 resistor into place is shown in Figure 7-14.
