Make a Mind-Controlled Arduino Robot by Tero Karvinen & Kimmo Karvinen

Make a Mind-Controlled Arduino Robot by Tero Karvinen & Kimmo Karvinen

Author:Tero Karvinen & Kimmo Karvinen [Tero Karvinen]
Language: eng
Format: epub
Tags: COMPUTERS / Hardware / General
ISBN: 9781449311537
Publisher: Make
Published: 2011-12-14T16:00:00+00:00


Warning

Always use strong batteries carefully. Acquire and follow battery-specific instructions. A short circuit can lead to heating, fire, or even explosion.

Connecting the Battery and Power Key

Batteries often use one set of cables for charging and other for discharge (powering your device). In our battery, the blue connector is for discharge and small white one is for charging (Figure 2-11). Be careful to use the correct one.

Let’s connect the battery and the key switch. The ground wire from the battery connects directly to Arduino, but the positive wire has a power switch in the middle (Figure 2-12). You need to use a connector for the battery, so that you can disconnect it for charging.
