Everything Electrical How To Test Circuits Like A Pro Part 1 by Keler Vincent

Author:Keler, Vincent [Keler, Vincent]
Language: eng
Format: epub
Published: 2015-03-08T16:00:00+00:00

For the Power Side Opens:

(The first step to take to finding a power side open is to connect one test probe to a part of the negative side of the circuit and then use the second test probe to check for voltage on various points in the power side. In this image we are checking both sides of the circuit’s fuse. If there is voltage present on both sides, this lets you know that there is nothing wrong with the fuse and the wiring from the fuse going back towards the battery. Also notice that the light bulb for the circuit has been reconnected after finishing the previous testing to find the side that the open was on.)
