Chemical Reaction Technology by Murzin Dmitry Yu

Author:Murzin, Dmitry Yu. [Murzin, Dmitry Yu.]
Language: eng
Format: epub
Publisher: De Gruyter
Published: 2015-04-28T16:00:00+00:00

Fig. 9.1: Simplified flow sheet of a medium-pressure process: 1, ammonia evaporator; 2, ammonia stripper; 3, ammonia preheater; 4, ammonia gas filter; 5, ammonia-air mixer; 6, air filter; 7, air compressor; 8, tail-gas preheater III; 9, reactor; 10, waste-heat boiler; 11, tail-gas preheater I; 12, economizer; 13, tail-gas preheater II; 14, feedwater preheater; 15, cooler-condenser; 16, absorption tower; 17, ammonia-tail-gas mixer; 18, catalytic tail-gas reactor; 19, tail-gas expansion turbine; 20, feedwater tank with deaerator; 21, steam drum; 22, steam turbine; 23, steam turbine condenser; 24, bleacher.
