Figure 8.7 List of general electrical symbols in current use.

such as those listed in Figures 8.11A, B, C. The use of these symbols simplifies considerably the preparation of piping drawings and conserves a considerable amount of time and effort.

In residential applications, plumbing information can often be provided on the floor plans in the form of symbols for fixtures and notes (for pipe sizes, slope, etc.) for clarification. Other plumbing items and information to be shown on the floor plans include water connections, floor drains, vent pipes, and sewer connections. Floor drains are shown in the approximate location on the plans and sections, with notes indicating the size, type, and slope to drain. Sewer and water-service lines are located in the position in which these utilities enter the building. Service lines are normally indicated on the site plan. Vent pipes
