Autodesk Revit Architecture 2014 Essentials by Reist Hathorn Tessa Duell Ryan Hathorn Tobias & Tobias Hathorn & Tessa Reist Hathorn

Autodesk Revit Architecture 2014 Essentials by Reist Hathorn Tessa Duell Ryan Hathorn Tobias & Tobias Hathorn & Tessa Reist Hathorn

Author:Reist Hathorn, Tessa, Duell, Ryan, Hathorn, Tobias & Tobias Hathorn & Tessa Reist Hathorn [Reist Hathorn, Tessa, Duell, Ryan, Hathorn, Tobias & Hathorn, Tobias & Hathorn, Tessa Reist]
Language: eng
Format: epub
Publisher: Wiley
Published: 2013-04-01T14:00:00+00:00


You’re going to modify the east and west faces, moving each face 40′-0″ (12 m) closer to the center. Hover your mouse near the edge of the face of the upper mass. Select the face, and note the small temporary dimension and the 3D widget.

Click the blue text, and change the value to 260′-0″ (80 m). Do the same for the middle and lower east faces. Click the Finish Mass button on the ribbon to confirm your edits. Go back to the Schedule view. Note the gross floor area is closer to 3.25 million square feet (see Figure 7.31), or about 302,000 square meters.

FIGURE 7.31 Resulting gross floor area
