Stability Analysis and Control of Powertrain for New Energy Vehicles by Donghai Hu & Bifeng Yin

Author:Donghai Hu & Bifeng Yin
Language: eng
Format: epub
ISBN: 9789811650512
Publisher: Springer Singapore

Time history diagram and phase portraits of x2 obtained by simulation when ω2 = 2, ω2 = 5, ω2 = 20, are shown in Fig. 3.18. The initial values are set to be , and the load excitation frequency is set to be ω1 = 200. The Poincaré bifurcation diagram of x2 with variation of load excitation frequency is shown in Fig. 3.20 (Fig. 3.19).

Fig. 3.18Time history and phase portraits of x2 with different load excitation frequency

Fig. 3.19The Poincaré bifurcation diagram of x1 with variation of load excitation frequency ω2
