magnetically locks with the stator’s rotating field flux, just as in the following diagram:

Essentially, the rotor’s North and South poles will try to align themselves with the North and South poles of the stator, following them in rotation at an equal velocity. It is easy to see therefore why this type of machine is ideal for constant speed applications.

Now, there are a couple of different methods of supplying direct current to a synchronous motor’s rotor conductors and these will be covered under the construction section of this report. For the moment though, it is important to consider the fact that synchronous motors cannot actually reach synchronous speed without some external means of starting.

At rest, a synchronous machine’s rotor may at one instant be faced with an attractive force towards the field flux - when rotor and stator poles align with opposing polarities - and the next instant, be faced with a repulsive force - when poles align with like polarities. The net result is that the motor will be unable to rotate in any one direction thanks to the opposing forces acting upon it. Read on for the solution.
