A spacer as wide as the side trim (X) provides a solid registration surface for aligning the sides (R/S) while driving the screws.

and groove in each door panel, see Routing Inlays on page 28.

5 Cut the shelves (DD) and shelf cleats (EE) to size [Drawing 5|. Lay out and cut the biscuit slots in the door sides (AA) and the ends of the shelves. Sand to 220 grit the inside faces of the door sides, tops/bottoms (BB), and panels (CC), and all surfaces of the shelves and shelf cleats. Set the cleats aside for now.

6 Place one door side (AA) inside face up on your bench. Apply glue to the dadoes at each end and add a door top and bottom (BB). Glue the panel (CC) in next. Apply glue in the biscuit slots in the door side and shelf (DD) and to the rear edge of the shelf, then glue the shelf in place. Add the remaining door side, then, using the cabinet as a helper, square the assembly |Photo L]. After the first door dries, assemble the other door the same way. (Save the spacers used under the doors. You'll need them later as you test the doors' fit.) Sand the outside surfaces of the doors to 220 grit. Install the door pulls [Drawing 5|.

woodmagazine.com

DOOR

%" rabbets Vs" deep

Optional

3 /a x Ve x 2" butterfly keys,

see page 28

14 3 /l6

.-^1

39%"

#10 biscuit slot, centered

Install the doors and finish it up

ICut spacers to support the doors next to the case in the open position |Photo M|. Center each door between the upper side trim (X) and lower side trim (W). Cut two pieces of continuous hinge to 39 3 /4 n . Position a hinge on each door and side (R/S) and install four evenly spaced screws on each half of the hinges.
