Qdrawer front and back dado setup for lock-rabbet joints

Cut a W rabbet Vi" deep into both ends of the drawer-box front and back.

W shim -""

Va° 1

v Zero-clearance insert

IN

VV' dado blade

position and blade height, cut dadoes into two scraps [Photo B], and check that they join snugly end-to-end. Once you achieve a tight fit, dado both ends of each drawer side [Photo Q.

To rabbet the box fronts and backs, attach the W shim to the fence using double-face tape [Drawing 5], and then rabbet the end of a scrap [Photo D] to test the fit with the dadoes cut in the previous step. Next, cut a rabbet on both ends of each drawer front and back. Fine-tune the fit using a block with 120-grit sandpaper on one face [Photo E). The joint

\v
