5.3 12T-TFET Master-Slave Flip-Flop (MSFF) Design

We propose a new TFET-FF design [71] that does not suffer from the issues of the aforementioned designs using a 2T-TFET latch and a 2T-TFET tri-state inverter as shown in Fig. 5.7; the unidirectional property of TFETs allows implementation of the tri-state inverter by using only two transistors. The input (D) is connected to the input of tri-state inverter (I1) consisting of M0 (PTFET) and M1 (NTFET). When the clock (CLK) is low, M0 and M1 work as an inverter. When CLK is high, inverter I1 is in tri-state because M0 and M1 have reverse-biased V GS. Similarly, the other inverter I2 (M4 and M5) is in tri-state when CLK is low and works as inverter when CLK is high. Master and slave latches are implemented using the NDR property of TFETs [14]. The operation of the NDR-based latch is similar to that of the SRAM latch shown in Fig. 3.​19 with gate bias voltages replaced by CLK and CLKN signals in order to implement a tri-state latch. Output drivers are used to isolate the internal storage latch from the fan-out. The proposed design implements flip-flops with inverted output using 12-TFETs and with non-inverted output using 14-TFETs.

Fig. 5.7Proposed 12T (14T with O/P driver-2) TFET-FF design [Ⓒ2016 IEEE]
