Va" ID. HOSE x V&" M.i.P. HOSE SARS T-shaped adapter for vacuum gauge "\ Muffler reduces noise of air blowing out of venturi valve. COUPLING v V O.P. Poly Tube connects vacuum system to jig or accessory. VENTURI VALVE COUPLING NOTE: We used a brass hose barb to connect the vacuum system to the air tube. It’s not included in basic kit. VENTURI COUPLING Use Shutoff valve to apply (or release) vacuum. Hose supplies air from compressor. Filter screens dust to prevent clogging venturi valve. Quick-release Coupler VENTURI VALVE DETAIL ► Vacuum gauge lets you monitor the amount of vacuum at the jig. Quick-release Fitting Regulator adjusts air pressure from compressor. As compressed airflows through venturi valve, outside air is drawn from vacuum area in jig. Air pressure gauge measures air pressure from compressor. NOTE: To assemble this vacuum system, • page 31 for sources. NOTE: To produce a vacuum with our venturi valve, we used a hp air compressor that supplies 2 CFM of air. If you use a different venturi valve, ask the manufacturer to match it to your compressor. Sealed vacuum system mount V4" Plexiglas mounting plate It’s one thing to establish a vacuum in each of the jigs. But to maintain that vacuum, you have to keep outside air from leaking back in. BACKER ROD. The key to sealing out this am is a V4" dia. strip of foam called backer rod , see photo at right. material for sealing ah* out of the vacuum as well. One reason is the foam has * just enough “give” to fit snug in the grooves that are routed in each jig. And even though it's compressed when the vacuum that provide materials for contractors. (It costs about a penny a foot.) If you Foam Backer Rod FEATURE PROJECT Typically, it's used to fill gaps or cracks around doors and windows before they're caulked. But it's the perfect applied, the foam springs right back. SOURCES. Backer rod is available from many building supply companies can't find it locally, you can order it from a company called Comtmction Materials by calling (515) 263-9006. No. 40 wmmmmm. mm ShopNotes 17
