FIGURE 7.11 Calculation of path clearance.

FIGURE 7.12 Received power relative to free space versus normalized path clearance: PEC sphere (146 MHz, 80 km path, 94 m transmitter height, varying receiver height), knife edge, and reduced reflection coefficient interference.

The horizontal axis of Figure 7.12 is expressed in terms of the ratio of the clearance h to the radius F1 of the first Fresnel zone. In the unobstructed region h is measured, as usual, from the point where the reflection occurs. It can be shown that, for a smooth sphere, this point corresponds to the minimum value of h′/F1 along each path, where h′ is the distance from the path to the surface, perpendicular to the surface. This property was used in calculating Figure 7.12. In Figure 7.12 the abscissa is labeled in h/F1 (dimensionless) units, and the ordinate is the (also dimensionless) ratio of the actual field strength, , to what it would be in free space, .
