The next page shows a wiring diagram for a strat using a Varitone switch instead of a lever switch. Notice you get six different positions with the Varitone switch.

position 1 = neck

position 2 = neck and middle

position 3 = middle

position 4 = middle and bridge

position 5 = bridge

position 6 = neck and bridge

If you have a tele, or two pickup guitar, then you will have 3 additional positions that you can use if you want to. In the next diagram, capacitors are soldered to the lugs on the top half of the switch and then exit to ground. This setup will turn on the bridge pickup and a capacitor in positions 4, 5, and 6. The bigger the capacitor, the more bass your guitar will have.

position 1 = neck
