Summer of Simulation by John Sokolowski & Umut Durak & Navonil Mustafee & Andreas Tolk

Author:John Sokolowski & Umut Durak & Navonil Mustafee & Andreas Tolk
Language: eng
Format: epub
ISBN: 9783030171643
Publisher: Springer International Publishing

All eventIn ports of States should be connected to an input port of a FSM.

Each stateOut port of State could either be connected to an individual output port of a FSM or connected together as one output port of a FSM.

All the states in a FSM are encoded as integer numbers (stateCode) during simulation. The state with the stateCode 0 is the initial state in the FSM.

After executing this model in CD++ with a set of external events, we obtain the results in Fig. 7.3. The left column shows the inputs, and the right column, the outputs obtained when we test it.

Fig. 7.3Execution of the ATM machine model in CD++
