Let's see how we might actually construct a doorway in the perspective center of a wall. We'll start with a wall whose perspective center line we've already found. The top level of the doorway is already indicated.

The easiest way to proceed (there are other ways involving more geometry) is to estimate where you want one of the vertical sides of the doorway and draw it in. Here I've put in the right-hand side.

Using the perspective Center

What I would really do next is simply draw in the left-hand edge a little closer to the perspective center line than I drew the right-hand edge. But to get it where it belongs through construction, mark the center of the height of the doorway. Measure between the top and bottom of the doorway with a ruler, or just eyeball it. For practical purposes, this will be the perspective center of the doorway.
