Design Drawing by Francis D. K. Ching

Design Drawing by Francis D. K. Ching

Author:Francis D. K. Ching [Ching, Francis D.K.]
Language: eng
Format: epub, pdf
ISBN: 978-1-118-06158-9
Publisher: Wiley
Published: 2010-03-13T05:00:00+00:00


In order to reveal a more complex composition, the cut may follow a three-dimensional route. In this case, the trajectory of the cut should clarify the nature of the internal organization and arrangement and be clearly articulated by a contrast in line weights or tonal values.

Even though a portion is removed in a cutaway view, its presence can remain in the drawing if we delineate its outer boundaries with a dotted, dashed, or delicate line. Indicating the external form of what is removed helps the viewer retain a sense of the whole.

While a paraline is a single-view drawing useful in displaying three-dimensional relationships, a series of paraline views can effectively explain processes and phenomena that occur in time or across space. A progression of paraline drawings can explain a sequence of assembly or the stages of a construction, with each view successively building upon the preceding one.
