Cloud Computing for Engineering Applications by Benito A. Stradi-Granados
Author:Benito A. Stradi-Granados
Language: eng
Format: epub
ISBN: 9783030404451
Publisher: Springer International Publishing
Fig. 3.9 Grid menu
11. Draw a square with 40-mm side length and round the corners to 4.50-mm radius.
This is the first geometry drawn; consequently, we would like to get it right the first time.
11a. Make sure that when drawing the characteristics of the figures remain proportional upon a change in size. This means if you draw a square and change the dimensions of one side, the other sides should follow suit.
11a1. Go to Tools
11a2. Options
11a3. Go to Sketch, Relations/Snaps and enable Automatic relations.
The presence of snapping is a matter of individual preferences.
