Auxtltar extension +

Zero-clearance throat plate

WWWtWOOdunllno.com

W round-over rdtam.

1" diam.

-%■ rabbet }V deep

3 Aligning your router-table fence Hush with the bit's pilot bearing, rout rabbets along the edges of the blanks for pans H and I. where shown on Drawings 3 and 4.

4 Trim off ihe ends of the blanks for parls H. K J. and K. as shown in Photo B, Then cut Ihe peneil cup and paper clip holder backs, fronts, and sides to their marked finished lengths,

5 Apply glue to the rabbets, and clamp the fronts, backs, and sides together, where shown tin Drawings 3 and 4. Keep the tops of the assemblies even, With the glue dry. sand the sides flush. Tape a sheet of 120-gril sandpaper to a flat surface, and sand the bottoms Hat.

6 Using your table-mounted router, rout ■//' round-overs on the top edges of assemblies H/J and I/K, where shown. Finish-sand the assemblies.

ZRcsaw and plane a laeewood blank to Vix2xl2" for the magnet holder (U. crest (M>. and spacers (N).

8 Referring to the Cutting Diagram, lay out the magnel holder (L) and the crest (M) on opposite ends of the blank. Mark hole centers, where shown on Drawings 1 and 4. Chuck a IW Forstner bit in your drill press, and drill

a W-deep counterbore. centered on (he magnet holder. Switch lo u V Forstner bit, and drill a hole centered in the counterbore. and then drill a hole at the marked centerpoint on the crest

9Rip ihe blank to l 7 A" wide, the width of the magnet holder (L). and then crosscut the magnet holder from the blank's end- Crosscut two VVMong pieces from the blank for the spacers (N). Rip the crest <M) to width, cutting through the 1"-diameter hole, and then
