5.6

Single-Net Routing

151

Example: Determining Routability

Given: (1) Nets A and B, (2) the layout area with routing regions and obstacles (left), and (3) the corresponding connectivity graph (right).

Task: Determine the routability of A and B.

1

2

3

1

2

3

3,1

3,4

3,3

B

A

4

5

6

7

4

5

6

7

1,4

1,1

1,4

1,3

B

8

9

A

10

8

9

10

3,4

3,1

3,3

Solution:

Net A is first routed through nodes (regions) 4–5–6–7–10, which is the shortest path. After this assignment, the horizontal capacities of nodes 4–5–6–7 are

exhausted, i.e., each horizontal capacity ¼ 0.

1

2

3

3,1

3,4

3,3

B

A

4

5

6

7

0,3

0,1

0,4

0,2

B

A

8

9

10

3,4

3,1

2,2

The shortest path for net B was previously through nodes 4–5–6, but this path would now make these nodes’ horizontal capacities negative. A longer (but

feasible) path exists through nodes 4–8–9–5–1–2–6. Thus, this particular

placement is considered routable.

1

2

3

2,0

2,3

3,3

B

A

4

5

6

7

0,2

0,0

0,3

0,2

B

A

8

9

10

2,3

2,0

2,2

152

5

Global Routing

5.6.3

Finding Shortest Paths with Dijkstra’s Algorithm

Dijkstra’s algorithm [6] finds shortest paths from a specified source node to all other nodes in a graph with nonnegative edge weights. This shortest path is based on various path costs, such as edge weights, between two specific nodes in the routing graph—i.e., from a source to a particular target. The algorithm terminates when the minimum path cost to a target node is found. As the routing space is represented as a (graph) grid, this type of path search is often referred to as maze routing.

Dijkstra’s algorithm uses a data structure for storing and querying partial

solutions sorted by path costs from the start. With this, it belongs to the class of best-search algorithms which explore a graph by expanding the most promising node chosen according to a specified cost calculation.

Dijkstra’s algorithm takes as input (1) a graph G(V,E) with nonnegative edge weights W, (2) a source (starting) node s, and (3) a target (ending) node t. The algorithm maintains three groups of nodes—(1) unvisited, (2) considered, and (3) known. Group 1 contains the nodes that have not yet been visited.

Group 2 contains the nodes that have been visited but for which the shortest-path cost from the starting node has not yet been found. Group 3 contains the nodes that have been visited and for which the shortest-path cost from the starting node has been found.

Dijkstra’s Algorithm

Input: weighted graph G(V,E) with edge weights W, source node s, target

node t

Output: shortest path path from s to t

1

group1 = V

// initialize groups 1, 2 and 3

2

group2 = group3 = path = Ø

3

foreach (node node 2 group1)

4

parent[node] = UNKNOWN

// parent of node is unknown, initial

5

cost[s][node] = 1

// cost from s to any node is maximum

6

cost[s][s] = 0

// except the s-s cost, which is 0

7

curr_node = s

// s is the starting node

8

MOVE(s,group1,group3)

// move s from Group 1 to Group 3

9

while (curr_node != t)

// while not at target node t

10

foreach (neighboring node node of curr_node)

11

if (node 2 group3)

// shortest path is already known

12

continue

13

trial_cost = cost[s][curr_node] + W[curr_node][node]

14

if (node 2 group1)

// node has not been visited

15

MOVE(node,group1,group2)

// mark as visited

16

cost[s][node] = trial_cost

// set cost from s to node

17

parent[node] = curr_node

// set parent of node

(continued)

5.6

Single-Net Routing

153

18

else if (trial_cost < cost[s][node]) // node has been visited and

// new cost from s to node is lower

19

cost[s][node] = trial_cost

// update cost from s to node and

20

parent[node] = curr_node

// parent of node

21

curr_node = BEST(group2)

// find lowest-cost node in Group 2

22

MOVE(curr_node,group2,group3)

// and
