2nd generation: iPad 2

3rd generation: The New iPad

4th generation: iPad with Retina Display

Crazy, isn’t it? At least you can easily identify the 4th generation model by observing its anodized aluminum rear case and Lightning connector.

External Anatomy

Figures 8.1 through 8.4 show you the external structure of the 2nd generation iPad.

FIGURE 8.1 iPad 2nd generation top view.

FIGURE 8.2 iPad 2nd generation front view.

FIGURE 8.3 iPad 2nd generation rear view.

FIGURE 8.4 iPad 2nd generation bottom view.

The biggest news for you from a disassembly perspective is that, beginning with the iPad 2, Apple began affixing the front panel assembly to the rest of the case by using copious (and I do mean copious) amounts of adhesive. This is in stark contrast to the first generation iPad, whose front panel is attached to the rear case by easy-to-remove clips.
