Selected Sensor Circuits by Peter Baumann

Author:Peter Baumann
Language: eng
Format: epub
ISBN: 9783658382124
Publisher: Springer Fachmedien Wiesbaden

One obtains ε = 5.58–10−6 1/N F.

Analysis

PSpice, Edit Simulation Profile

Simulation Settings – Fig. 5.4: Analysis

Analysis type: DC Sweep

Options: Primary Sweep

Sweep variable: Global Parameter

Parameter Name: F

Sweep type: Linear

Start value: 0

End value: 150

Increment: 10 m

Edit diagram:

Trace, Add Trace

Trace Expression: F*5.58E-06

Apply: OK

PSpice, run

The dependence of the strain ε on the weight force F is shown in Fig. 5.8. Figure 5.8 shows that the strain increases linearly with the weight force.

Fig. 5.8Elongation as a function of the weight force in Newton
