Figure 10-3. BGP-4 Address Assignment Between PE- and CE-routers

Given the address assignments within Figure 10-3, the PE-router configuration, similar to the one in Example 10-1, can be used to configure BGP routing on the SuperCom San Jose PE-router. Notice within this configuration the use of address families under the BGP process for each VPN customer, and the relevant BGP session configurations for each customer under the address-family.

Example 10-1. PE-to-CE BGP-4 Configuration Example

hostname San Jose

!

interface serial0

description ** interface to FastFoods San Jose **

ip vrf forwarding FastFoods

ip address 195.12.2.6 255.255.255.252

!

interface serial 1

description ** interface to EuroBank San Francisco **

ip vrf forwarding EuroBank
