Mastering Autodesk Revit 2020 by Robert Yori & Marcus Kim & Lance Kirby

Author:Robert Yori & Marcus Kim & Lance Kirby
Language: eng
Format: epub
ISBN: 9781119570226
Publisher: Wiley
Published: 2019-10-29T00:00:00+00:00

The next step is to customize the Rated Walls filter so that items that fall into the filter category will have a specific graphic override applied. First, set the Foreground Projection/Surface override for Patterns to Red and Diagonal Crosshatch, and leave the Background settings as-is. To do this, select the Override button under Projection/Surface - Patterns to bring up the dialog box shown in Figure 12.36. You will also want to choose the Override button for both Lines and Patterns under the Cut heading and set each of their colors to Red, as you just did for line graphics. (Note that you can specify whichever fill pattern you want. Diagonal Crosshatch was selected for this exercise for clarity of the figures.)

FIGURE 12.36 Graphic overrides
