Figure 9.10 – The purple lines of the Intersect tool on the reference models

Within the MODIFY panel, select Offset and set it to 2 mm for the bottle edge.

For the right edge, we will draw a line from the endpoint.

Select the LINE tool and try to pick the endpoint of the cylinder extruded base. You will notice that you may not be able to since there are no endpoints on a cylinder corner. So, instead, we will project in the top edge of the cylinder so that we can connect to the right-side endpoint.

Select the LINE tool once more, if you accidentally selected out of it, and pick on the edge of the cylinder (see Figure 9.11). This will automatically project in the edge, which will show a purple dot at the end that we can constrain to.
