How To Use A Digital Multimeter: The Practical Guide to Learn How To Use A Digital Multimeter To Measure Current, Voltage, Resistance And Other Quantities, Troubleshoot And Fix Anything Electrical by Alvin Matt

Author:Alvin, Matt [Alvin, Matt]
Language: eng
Format: epub
Published: 2022-08-18T00:00:00+00:00

Driver medium

Cables : Cables are generally made up of a set of copper wires (conductor) and are covered by a plastic sheath (insulator). Before connecting a cable to a component, you must peel the plastic and twist the copper wires, since a small thread that is left loose can cause failures in the circuit if contact is made where it should not.

When you design a somewhat complicated circuit, it is important that you differentiate between the wires that are connected and those that cross without connection, so that you do not make mistakes in the practical assembly.

Prototyping board or Protoboard : Prototyping boards are used to test circuits to make sure they work before soldering components into the final circuit. It is used for the assembly of electronic circuits.

Printed circuit boards : You can build a circuit using a printed circuit board. In it, the electric current circulates through copper paths and the components are soldered to the plate with tin.

Receivers

Receivers are those elements that can use the passage of an electric current to produce an effect. They convert electrical energy into a different type of useful energy. Among them are motors, lamps, resistors, buzzers, and so on.
