The Structure of the Comparative Software Model

The comparative software model of effective methods for analyzing laser radiation parameters has a modular structure, shown in Fig. 19.

Figure 19. Modular structure of comparative software model of effective methods for analysis of laser radiation parameters

The main module of the model contains the entry point in the program, and also performs the basic logic of the work of the software model. The filter library is used to preprocess the images by providing the corresponding functionality for the main module. Analysis of parameters of laser radiation on the basis of images of the profiles of laser beams implemented directly in the module of image processing. Constant storage module contains all the necessary constants for the program model to work.

A comparative software model of effective methods for analyzing laser radiation parameters is created using the Java programming language and has the following object-oriented structure (Figure 20).

Figure 20. Object-oriented structure of the comparative software model
