Gun Digest Ruger 10/22 Assembly/Disassembly Instructions

Author:Kevin Muramatsu [Muramatsu, Kevin]
Language: eng
Format: epub
Tags: Crafts; Hobbies & Home, Antiques & Collectibles, Firearms & Weapons
ISBN: 9781440231667
Amazon: B006PHZ606
Publisher: Gun Digest Books
Published: 2011-11-11T05:00:00+00:00

13. Hold the trigger back to remove sear tension from the hammer, and push out the hammer pivot cross pin. Remove the hammer assembly upward. The bolt latch spring encircles the hammer bushing on the right side, and the two hammer pivot bushings are easily removed from the hammer.

14. Note the position of the sear and disconnector in the top of the trigger before disassembly. Push out the trigger pivot cross pin, and remove the trigger/sear/disconnector assembly upward. As the trigger is moved upward, the trigger spring and plunger will be released at the rear of the trigger guard. Ease them out, and remove them downward and toward the front.
