Gun Digest Colt 1911 Assembly/Disassembly Instructions by J.B. Wood

Author:J.B. Wood
Language: eng
Format: epub
ISBN: 978-1-4402-3173-5
Publisher: F+W Media
Published: 2011-10-10T04:00:00+00:00

12. Removal of the firing pin retainer plate also frees the extractor. With a small screwdriver pry it gently out, straight to the rear of the slide.

13. When the extractor is pried out past its round headpiece, it can be easily grasped with the fingers and removed from the slide. The rear sight can be drifted out of its dovetail slot from left to right.

14. The initial takedown key for the frame is the mainspring housing retaining pin, located at the lower rear edge of the grip frame.

15. With the hammer at rest, use a drift of the proper size to drive out the mainspring housing retainer pin.
